Nail Polish Automatic Filling Machine

This Nail Polish Automatic Filling Machine integrates the functions of automatic bottle feeding, automatic positioning, filling, brush inserting, and capping. It is widely used in pharmaceutical, biological, daily chemical, chemical and other industries.

Automatic Air Cleaning Filling Capping Machine for Nail Polish

Main process:

1, Bottle rotary feeding table(option)

2, Nail polish filling machine

– Air Cleaning (optional)

– Metal ball feeding(optional)

– Liquid filling

– Brush automatic feeding inserting

– Automatic capping

– Final product output


1, With touch screen & PLC control, with functions such as no bottle no filling, no bottle no capping and no bottle automatic shutdown. Variable frequency speed regulation, continuously adjustable operating speed.

2, The filling head reaches about 2/3 of the bottle to start filling, filling while rising, to prevent the liquid from foaming due to large impact, no bottle no filling, no bottle no capping.

3, Intelligent control of filling volume: the touch screen directly inputs the filling volume, and the filling volume is automatically calibrated. It is very convenient to switch between different specifications and adjust the loading volume, and there is no requirement for the level of the operator. Avoid the trouble of traditional test while adjusting.

4, Equipped with brush guide correction function.

5, Torque adjustable torque type capping mechanism, the effect is far better than conventional capping; torque adjustment is fast and convenient, can be completed in a few seconds.

6, Overload protection and alarm prompt function, more safe and reliable.


Filling volume10ml (can be customized)
Capacity1500~2500 (bottles/hour)
Air source0.6-0.8MPa
Power supply220V/50Hz, 2.5kw
Total Weight600kg


Bottle type

No limits for bottle shapes. Can customize for special needs.
